High Temperature Glass Wool Roll




Overview

Density: 12-24kg/m³

Width: 1200mm

Thickness:50/75/100/150/200mm

Material: Fiber Glass Wool

Place of Origin: China


Available size

Density

Thickness

Width

Conductivity

R-Value

Packing

PKG/40HQ

(kg/m3)

(mm)

(mm)

(W/m.k)

(㎡.K/W)

(pcs/PKG)

(NO#)

12

50

1200

0.037

1.35

1

Loading Qty.

Please consult

12

75

1200

0.037

2.02

1

12

100

1200

0.037

2.70

1

12

150

1200

0.037

4.00

1

12

200

1200

0.035

5.50

1

16

50

1200

0.035

1.42

1

16

75

1200

0.035

2.14

1

16

100

1200

0.035

2.85

1

24

50

1200

0.033

1.50

1

24

75

1200

0.033

2.25

1

24

100

1200

0.033

3.00

1

Conductivity Value tested under temperature in 23

Consult your local sales representative for other available sizes and specification

Physical Properties

Tested Content

Tested Method

Tested Value

Density

ASTM C612

24kgs/

Thickness

GB/T 13350-2008

50mm

Average diameter of fibers

GB/T 13350-2008

6.8μm

Coefficient of Heat Conductivity

EN12667

0.035W/m.K

Thermal Resistance

ASTM C653

1.40m2.K/W

Average NRC

EN ISO 354

1.05

Maximum Service Temperature

ASTM C411

400

Corrosion Resistance

ASTM C665

No Chemical Reaction

Mold Resistance

ASTM C665

Mildew proof

Moisture Absorption

ASTM C1104

Less 3% by weight

Humidity veneration Rate

ASTM E96

Max 0.013g/24Hours.m2

Non-Combustibility

ASTM E84

Flame Propagation:25;Flame Diffustivity:50

Available facings

FSK,ASJ facing is available accordingly to project design.

Packaging

Glass wool roll are packed by vacuumed packing, inner packing is PVC bag, Outside packing is woven fabric bag. It will save transportation cost and save storage space.
